Product Overview
No Sales Tax — shipped from Portland, Oregon.
The Astra P1 is a 4K60 PTZ camera built for churches, halls, and live productions that need broadcast-quality multi-camera coverage without a full camera-operator crew. A 30x optical zoom, AI-driven presenter tracking, and built-in NDI|HX3 support let one operator (or no operator at all, once zones are configured) cover a stage reliably, streaming clean 4K over a single PoE+ Ethernet cable.
Key Features
- UHD 4K60 imaging from a 1/1.8" sensor — clean, low-noise footage even in dim venue lighting
- 30x optical zoom (16x digital) with f/1.6 aperture for tight close-ups from the back of a room
- AI Auto Tracking: Presenter Tracking follows a speaker automatically; Zone Tracking covers up to 4 preset areas (podium, stage, etc.)
- Face Detection AE keeps exposure locked onto the presenter even as stage lighting shifts
- Built-in NDI|HX3 license included — no extra licensing cost, works directly with OBS/vMix
- Single PoE+ cable carries 4K video, audio, power, and control — no separate power run needed
- Simultaneous HDMI 2.0, 3G-SDI, USB, and LAN output; supports VISCA/Pelco/FreeD control protocols
- 5-year warranty (3-year standard + 2-year with product registration)
Specifications
| Image Sensor | 1/1.8" CMOS, 8.42MP effective |
| Optical Zoom | 30x (f=7.1–210mm), 16x digital |
| Video Output | 4K60 via HDMI 2.0 / 3G-SDI |
| Pan / Tilt Range | Pan ±170°, Tilt −30° to +90° |
| Preset Positions | 255 (0.1° accuracy) |
| Power | DC 12V or PoE+, 18W max |
| Dimensions | 169 × 188 × 226mm |
| Weight | ~2.3kg |
What's in the Box
- Transmitter x1
- Easy-Install Short Antenna x4
- USB-C OTG Adapter x1
- 1/4" Cold Shoe x1
- Quick Guide x1
- Warranty Card x1
